BeautyCell Workstation
Isolation Devices — New Trends in Biotechnology
GENERAL CENTRIFUGE, REFRIGERATED CENTRIFUGE (FOR NB-803MSF)
- Designed for multiple purposes such as cell or blood isolation.
- 24 standard tubes (15 ml) can be spun at a time.
SHAKING INCUBATOR
- The shaking incubator is used to mix samples with the medium or to incubate them after centrifugation
- Temperature and RPM can be adjusted via the waterproof control panel.
BIO-WORK STATION
- 99.99% HEPA Filter and UV sterilisation provide a pure environment.
- Air circulation can be set to strong or gentle.
- Air convection is of the laminar flow type so that it is isolated from the outside environment (air curtain).
FOOT SWITCH
- Designed to start and stop the Centrifuge and the Shaking Incubator hands-free.
HEPA FILTER
- Equipped to filter 99.99% of particles larger than 0.3 μm.
PRESSURE GAUGE
- By checking the manometer showing the internal air pressure, it allows you to notice filter failures and the filter replacement time.
CUSTOMISATION OPTION
- Customise your Multi Station with the device you would like to have installed in this work station
Main Specifications
| ITEMS | NB-803MS | NB-803MSF |
|---|---|---|
| Mail Filter | HEPA filter 99.99% efficiency on particies of 0.3╗m. | |
| Exhaust Filter | HEPA filter 99.99% efficiency on particies of 0.3╗m. | |
| Sterilization lamp | U.V 20Wx2ea. | |
CENTRIFUGE
| NB-803MS | NB-803MSF | |
|---|---|---|
| Max RPM | 5000 RPM | 5500 RPM |
| Max Force | 4612xg | 5580xg |
| Max Capacity | 480ml,15mlx32Tubes (Swing rotor) | |
| Temp range | -5°C~60°C | |
| Main Controller | DigitalPIDcontroller Inverter | |
| Drive System | Motor Drive | |
| Timer | 99hrs 59min & hold run | |
DIMENTIONS
| NB-803MS | NB-803MSF | |
|---|---|---|
| Work Space | 900x640x620(H)mm | 1200x600x620(H)mm |
| Overall | 900x790x1920(H)mm | 1200x825x1920(H)mm |
| Power | 110/220V, 50/60Hz, 800W | 110/220V, 50/60Hz, 1.2kW |
